ESE Lightning Protection System Model – 65

Earthway Technologies LLP is a leading ESE (Advanced Early Streamer Emission) lightning protection system manufacturer.

It protects against lightning strikes, which can cause the generation of fault currents with the potential to damage electrical equipment and pose risks to human life. Lightning strikes can damage electrical systems and pose risks to human life.

Our Benefit

Working Principle of ESE Lightning Protection System Model - 65

01

Atmospheric Electric Field

The system works by responding to the electric field intensity of the atmosphere, which drives electric currents in the charged environment.
02

Ion Generators Charging

The electric atmosphere conditions the interior of the system, ensuring the ion generators charge with these electrical currents.
03

Ionization for Conductivity

The ion generators ionize the surrounding atmosphere, enhancing conductivity and promoting rapid charge and discharge cycles to safely guide lightning strikes to the ground.
04

Thunderstorm Electric Field

During a lightning storm, the electrical charges in the cloud and the concentration of negative charges create a large electric field between the cloud and the earth's surface.
05

Electric Field Calculation

The electric field value, which ranges from 5kV/m to 30kV/m, is based on the concentration of charge in the thunderstorm clouds.
06

ESE Concept for Early Emission

The ESE system triggers an upward streamer earlier than traditional rods, effectively controlling the emission of the streamer for enhanced lightning protection.
Services

Application

Engines prime movers and exhaust gas turbochargers.

DALL·E 2024-12-14 09.18.30 - An industrial and residential setup showing the application of copper earthing electrodes for high_low voltage use. The image includes a power substat

Efficient Grounding System

Prevents electric arcs and fire hazards.
View Details
DALL·E 2024-12-14 09.20.47 - A visually detailed image depicting copper earthing electrodes in both domestic and industrial settings. On one side, a modern house with visible grou

Reliable for Applications

Supports power, telecom, and more
View Details
Gemini_Generated_Image_nd7qxnd7qxnd7qxn

Industrial Use

Ideal for power and communication setups.
View Details
Gemini_Generated_Image_dq6tu0dq6tu0dq6t

Accident Prevention

Reduces static charges and stray currents.
View Details
Gemini_Generated_Image_wiywf5wiywf5wiyw

Safety Compliance

Neutral Earth Systems
View Details
Gemini_Generated_Image_injjm2injjm2injj

Neutral Earth Systems

Ensures effective neutral grounding performance
View Details

Industries

Petrochemical, CNG, and Nuclear Facilities
Data Centre, Telecom and Broadcasters
Process control and automation Industries
Hospital, Government, Military, and defence

Get An Enquiry

Call Us Now

Technical Specification

Model Length (Mtr) Dia (Available) MM 100 88 65 50
3000MM GI 1 100 88 65 50 40
2000MM GI 2 100 88 65 50 40
1500MM GI 1.5 100 88 65 50 40
1000MM GI 1 65 50 40

Some Key Points About Hot Dip GI Earthing Electrodes

01

Material

The electrode is typically made of galvanized iron, which is iron or steel coated with a layer of zinc through the hot-dip galvanizing process. This process helps to protect the iron from corrosion, ensuring the longevity and effectiveness of the earthing electrode.
02

Hot-Dip Galvanizing

The hot-dip galvanizing process involves immersing the iron or steel electrode in molten zinc, creating a protective layer that adheres to the surface. This layer helps to prevent rust and corrosion, making the electrode more durable and suitable for outdoor use.
03

Function

The primary function of a Hot Dip Galvanized Iron Earthing Electrode is to dissipate fault currents safely into the ground, preventing the accumulation of excess voltage in electrical systems. This helps in stabilizing the system and protecting equipment and personnel.
04

Installation

The electrode is typically buried in the ground to ensure good contact with the soil. The effectiveness of the earthing system depends on factors such as the soil resistivity, depth of burial, and the number of electrodes installed.
05

Advantages

Corrosion Resistance: The hot-dip galvanizing provides excellent corrosion resistance, ensuring a longer lifespan for the electrode. Reliability: Galvanized iron is a sturdy material that can withstand harsh environmental conditions, making it a reliable choice for earthing electrodes. Low Maintenance: Galvanized coatings require minimal maintenance, reducing the need for frequent inspections or replacements.
06

Applications

These electrodes are commonly used in various electrical applications, including residential, commercial, and industrial installations, as well as in power distribution systems. In conclusion, Hot Dip Galvanized Iron Earthing Electrodes stand as reliable guardians of electrical systems, ensuring safety and efficiency by providing a robust pathway for the dissipation of fault currents into the ground. With their durable construction and corrosion-resistant coating, these electrodes offer long-lasting protection against the corrosive forces of the environment.
