| Specification | Details |
|---|---|
| Base Material | Low Carbon Steel |
| Base Coating Material | Copper |
| Coating Material | 99.9% Pure Electrolytic Grade Copper Anode |
| Available Coating Thickness | 50-250 Micron (Average) |
| Available Diameter (mm) | 14.5, 16, 17.2, 20, 25, 32 |
| Available Length (m) | 1 meter to 3 meter |
| Terminal Dimension (optional) | 40×6, 50×6 |
| Model | Length (Mtr) | Dia (Available) | ||||
|---|---|---|---|---|---|---|
| MM | MM | MM | MM | MM | ||
| 3000 MM CBR | 3 | – | 16 | 17.2 | 20 | 25 |
| 2000 MM CBR | 2 | – | 16 | 17.2 | 20 | 25 |
| 1500 MM CBR | 1.5 | 14.5 | 16 | 17.2 | – | – |
| 1000 MM CBR | 1 | 14.5 | 16 | 17.2 | – | – |
The versatility of copper Bonded rods makes them suitable for a wide range of applications:
At Earthway Technologies, we are committed to providing high-quality copper threaded rods that meet your exact requirements. Our products ensure safety, durability, and efficiency in all your applications.
Contact us today to learn more about our custom solutions and get a quote!
A copper Bonded rod is a long, cylindrical rod with threads along its length, typically used for electrical grounding, mechanical applications, and construction projects.
Copper’s excellent electrical conductivity, corrosion resistance, and mechanical strength make it ideal for grounding and bonding applications.
Yes, copper’s natural corrosion resistance ensures reliable performance in outdoor environments, including humid and coastal regions.
Absolutely! At Earthway Technologies, we offer custom lengths, diameters, and threading specifications to meet your project needs.
Consider factors like:
Application Type: Electrical grounding, construction, or industrial use.
Length and Diameter: Select based on load-bearing or electrical requirements.
Environmental Conditions: Opt for coated rods for extreme conditions.
